Product Overview
Product Specification
Product Video
| High speed, long lifetime, high quality | Outstanding functions, Strong stability |
| Support Linux & Windows system | Support Chinese Gb18030 |
| Compatible with ESC/POS commands | |
| Model | XP-T503(XP-C503) |
| Printing Features | |
| Printing method | Direct thermal |
| Paper width | 57.5±0.5mm |
| Print width | 48 mm |
| Column capacity | 384 dots/line |
| Print speed | 90 mm/s |
| Interface | USB+WiFi, USB+4G, (Optional:WiFi+4G, Bluetooth) |
| Line spacing | 3.75mm (Adjustable by commands) |
| Media type | Continuous paper |
| Media width | 58mm |
| Media roll diameter | 60mm±0.5mm |
| Media thickness | 0.06mm~0.08mm |
| Fonts Symbology | |
| Character size | Afont A: 12x24, Font B: 9x17, CHN: 24*24 |
| Barcode types | UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 / QR code |
Extended character sheet | PC347(Standard Europe) / Katakana / PC850(Multilingual) / PC860(Portuguese) / PC863(Canadian-French) / PC865(Nordic) / West Europe / Greek / Hebrew / East Europe / Iran / WPC1252 / PC866(Cyrillic#2) / PC852(Latin2) / PC858 / IranII / Latvian / Arabic / PT151(1251） |
| Input buffer | 12 Kbytes |
| NV Flash | 64 Kbytes |
| Power | |
| Power adaptor | AC 100V/240V, 50～60Hz, 1.0A |
| Power source | DC 9V / 2A |
| Physical characteristics | |
| Weight | 0.57 kg |
| Dimensions | 161 × 130 × 93mm (D×W×H) |
| Environmental Conditions | |
| Operation environment | Temperature (0～45℃), humidity(10～80%) |
| Storage environment | Temperature(-10～60℃), humidity(10～90%) |
| Physical Reliability | |
| Printer head life | 50KM |
| Software | |
| Emulation | ESC/POS |
| Driver | Windows/ Linux/ Android |
| SDK | Windows / iOS / Android |
